Description
Coloured light module (SBM-FL75/150)
Coloured light module for LED lamps.
Allows to connect and control almost any RGB or white light LED light (e.g. LED-spots, LED-strips, etc.) via sauna control unit. No driver needed, LEDs are connected directly to the module.
Compatible with voltage-controlled (0 – 24 V) and with currentcontrolled (0 – 3000 mA) LED lamps.
Output: RGB (3 separately adjustable channels) and white light (may be synchronized with the main light). In Emotec design housing.
Available with two power outputs: 67,5 W and 135 W. Max 3 A per channel.
Not compatible with RGB LED strips with the common „+“ line.
Compatible control units:
- EmoTec series
- EmoStyle series
- EmoTouch 3
| Model | Item no. | Size (HxWxD) |
| SBM-FL75 module coloured light, 67,5 W | 945996 | 270 x 195 x 90 mm |
| SBM-FL150 module coloured light, 135 W | 946007 | 270 x 285 x 90 mm |
