Herkules XL S120 HD

The flagship of the Herkules series for intensive use in large commercial saunas.
The Herkules XL S120 set standards for superior performance, durability and sophisticated design.

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

0 People watching this product now!

Payment Methods:

Description

FLOOR-STANDING

The flagship of the Herkules series for intensive use in large commercial saunas.
The Herkules XL S120 set standards for superior performance, durability and sophisticated design.

Two separate rock stores with up to 120 kg stones ensure an excellent temperature stability and heat storage capacity. The unique construction with rock stores above the heating elements provides continuously high performance and reliability, strong air convection, long service life and easy maintenance.

All Hekules Xl S120 models have an upgraded special “heavy-duty” inner wiring with solid copper busbars for even more durability and long-lasting service even by unfavourable operation conditions in a commercial sauna.

Also available with high-quality matt black finish*



Optional: Heater guard rail with mounting brackets.

Power Item no.
18,0 kW 948116
24,0 kW 948117
30,0 kW 948118
18,0 kW – black* 948821
24,0 kW – black* 948822
30,0 kW – black* 948823

Specification

Temperature stability

Two separate rock stores with up to 120 kg stones ensure an excellent temperature stability and heat storage capacity.

Unique Construction

The unique construction with rock stores above the heating elements provides continuously high performance and reliability, strong air convection, long service life and easy maintenance.

Electrical connection

400 V 3N ~ 50/60 Hz

Fuse protection control unit

3 x 16 A / 3 x 16 A / 1 x 16 A

Fuse protection LSG unit

3 x 16 A / 3 x 35 A / 3 x 63 A

Dimensions H/W/D, in cm

85 / 96 / 53

For sauna cabin size (18 / 24 / 30 kW)

24 - 35 m³ / 35 - 45 m³ / 45 - 65 m³

Min. size air inlet and outlet (18 / 24 / 30 kW)

50 x 6 cm / 50 x 8 cm / 50 x 10 cm

Weight withouth rocks

85 kg

Stone filling

120 kg

Power extension required (18 / 24 / 30 kW)

LSG 10 / LSG 18 / LSG 36
